T6000
The powerful T6000 represents the next generation in industrial, high-performance thermal barcode printers. The T6000 is available with optional RFID and ODV barcode validation technologies.
T6000
High performance ARM Cortex-A9
Die-cast aluminum frame w/metal door
Transfer and direct printing
4″ and 6″ model configurations
Premium Asian and Andale font support
State-of-the-art WiFi connectivity
Available in 203 DPI and 300 DPI
512MB RAM / 128MB Flash Memory
4-32 GB SD memory card capability
ENERGY STAR Certified
PRINTING CHARACTERISTICS
Printer Memory: 512MB RAM / 128MB Flash
Printing Methods: Thermal transfer or Direct thermal
Resolution: 203/300 DPI
Max. Print Speed
14 IPS @ 203 DPI; 12 IPS @ 300 DPI [4″ model]
12 IPS @ 203 DPI; 10 IPS @ 300 DPI [6″ model]
Max. Print Width:
4.1” (104mm) [4″ model]
6.6” (168mm) [6″ model]
MEDIA SPECIFICATIONS
Media Types: Roll or Fan-Fold Labels, Tags, Paper, Film, Tickets
Media Thickness: 2.5 Mil (0.0025″) to 10 Mil (0.010″)
Roll Core Diameter: 1.5″ (37.5mm) to 3.0″ (76mm)
Max. Media Roll Diameter: 8.0” (209mm)
Media Sensing: Gap, Mark
Max. Media Length: Up to 99″
Media Width:
1.0” (25.4mm) to 4.5” (114.3mm) [4″ model]
2.0” (50.8mm) to 6.8” (172.7mm) [6″ model]
Min. Media Length:
0.25” / 1.0″ (Continuous/Tear-Off)
1.0″ (Peel-Off)
RIBBON CHARACTERISTICS
Ribbon Type: Wax, Wax/Resin, Resin
Coating: Coated side in, coated side out
Max. Ribbon Length: 450 Meters
Min. Ribbon Width:
1″ (25.4mm) [4″ model]
2″ (50.8mm) [6″ model]
Max. Ribbon Width:
4.5″ (114.3mm) [4″ model]
6.8″ (172.7mm) [6″ model]
PHYSICAL CHARACTERISTICS
Width:
10.9″ (276.9mm) [4″ model]
14.1″ (358.1mm) [6″ model]
Height:
12.3″ (312.4mm) [4″ model]
12.4″ (314.9mm) [6″ model]
Depth:
20.3″ (515.6mm)
Printer Weight:
33.6 lbs. (14.5Kg) [4″ model]
39 lbs. (17.4Kg) [6″ model]
Shipping Weight:
42.6 lbs. (18.6Kg) [4″ model]
48 lbs. (21.5Kg) [6″ model]
PRINTER LANGUAGE
IGP Languages: PGL/VGL/ZGL/TGL/IGL/DGL/IEGL/MGLIGP
Job Control Languages: PJL, XML, and PTX-SETUP
Optional Languages:
IPDS]
TN5250
PDF Level 1.7, Postscript Level 3
COMMUNICATION & CONNECTIVITY/INTERFACE
Standard Interface I/O: Serial RS232, USB, and Ethernet 10/100Base T
Optional Interface I/O: Parallel, WiFi (802.11a/b/g/n), GPIO
WiFi Security Protocol: WEP 40/128bit, WPA Personal (PSK), WPA2 Personal (PSK) and Enterprise (AES CCMP), EAP-TLS, EAP-TTLs, PEAPv0/MS-CHAPv2, PEAPv1, EAP-MD5
MEDIA HANDLING MODES
Standard: Continuous, Tear-Off Strip, Tear-Off
Options: Peel-Off, Cut, and Rewind
BARCODE VALIDATION
Online Data Validator (ODV): Validates, Grade, Report, and Overstrike bar codes
Supports 1D Barcodes (Picket Fence)
Compatible with RFID encoding
RFID
UHF EPC Gen2 / ISO18000-6C: Multi-position RF antenna, Advanced Printer Encoder Firmware encodes and validates Gen2 compliant tags
On-Pitch label to 0.625 in (depending on inlay)
PGL, ZPL, STGL, MGL language support
Counters track good / bad label encoding
OPERATING ENVIRONMENT
Operating Temperature: 40 to 104°F (5 to 40°C)
Operating Humidity: 20 – 85% Non-Condensing
Storage Temperature: 23 to 140°F (-5 to 60°C)
Storage Humidity: 5 – 85% Non-Condensing
POWER REQUIREMENT
Line Input: Auto Range 100 – 264 VAC (48 – 62 Hz)
REGULATORY COMPLIANCES
Emissions: FCC, CE, CCC
Safety: cTUVus, CE, EAC, SABS, RCM, CCC, KCC, S-MARK, NOM
Environmental: RoHS, WEEE, Energy Star
Radios (WiFi/RFID): FCC, CE, IC, and others based on market need
BAR CODE SYMBOLOGIES
1D Barcodes: BC-412, Code 11, Code 39, Code 35, Code 93, Codabar, Code128 Subsets A/B/C, Industrial 2 of 5, Interleave 2 of 5, German I-2/5, EAN-8, EAN-13, UCC/EAN-128, UPC-A, UPC-E, UPCSHIP, UPS 11, MSI, Matrix 2 of 5, PLESSEY, POSTNET, 4-state PostBar, Australian 4-state, FIM, ITF14, TELEPEN, PLANET, USPS Intelligent Mail, LOGMARS
2D Barcodes: PDF-417, MicroPDF-417, Maxicode, DataMatrix, QR Codes, Aztec, GS1 Databar (RSS-14)
FONT, GRAPHIC SUPPORT
Graphic Formats: PCX, TIFF, BMP, PNG
Font Technologies: Intellifont, TrueType, Unicode
Standard Fonts: OCRA, OCRB, Courier, Letter Gothic, CG Times, CG Triumvirate/Bold/Condensed
Asian Fonts (Optional SD card): Simplified Chinese, Japanese, and Korean
Andale Fonts (Optional SD card): Simplified Chinese, Traditional Chinese, Korean, Japanese
PDF/ PostScript Level 3: 35 Fonts
REMOTE MANAGEMENT SOFTWARE
PrintNet Enterprise Auto ID: Enterprise Grade Remote Management Solution
OPTIONS AND ACCESSORIES
WiFi 802.11 a/b/g/n (US/EU/CAN)
Parallel Port
GPIO
TN5250
PDF/PostScript
IPDS
Online Data Validator (ODV)
Rewind 4″/6″
Heavy Duty Cutter 4″/6″
Peel & Present 4″/6″
Premium Asian Font Cards
Andale Font Cards
QCMC (SD Quick Change Memory Card)
UHF RFID (US 902-928MHz, EU 866-868MHz)
